MPN 032720, 1/8" BSP, 5/2 with bi-directional lever and roller, 1 position. Mechanically operated valve
Technical Specifications
| Fluid | Compressed filtered air with or without lubrication. Lubrication, if be used, must be continued. |
| Pressure range | 0 ÷ 8 bar |
| Temperature range | -20℃ ÷ +80℃ |
| Orifice | 6 mm |
| Flow | 900 Nl/min |
| Connections | 1/8" |
| Fixing | Through holes on the body |
| Mounting | In any position |
| Materials |
Body: Painted die-cast aluminium |
