API RT160418 Push-in Fitting (DELRIN) (Made in Italy) - Watson Machinery Hydraulics Pneumatics

API RT160418 Push-in Fitting (DELRIN) (Made in Italy)

Regular price
US$6.46
Sale price
US$6.46

API Push-in fittings series RT
In Delrin

MPN 029161, TubeØ4 - 1/8" BSPT swivel elbow.
Body in acetal resin, Nickel plated brass screw with tefloned thread.

Technical Specifications

Fluid Compressed air
Pressure range 0,5 ÷ 12 bar (Vacuum resistance: 750mm.Hg)
Temperature range -20℃ ÷ +70℃
Parallel threads UNI-ISO 228/1 (BSP)
Taper threads UNI-ISO 7/1 (BSPT)
Metric threads ISO R/262
Connection tubes Calibrated nylon, Polyurethane and Rilsan
Tube tolerances ±0,05 mm
Materials

Body and release collar: Acetal resin (DELRIN)
Metal thread: Nickel plated brass
Collet: Stainless steel
Seals: Nitrile rubber (NBR)
