Parker Taiyo 10A-2 SD200B50 Heavy Duty Pneumatic Cylinder

Parker Taiyo 10A-2 SD200B50 Heavy Duty Pneumatic Cylinder

Regular price
Sale price

ISO-STANDARD, Non-lubrication type Heavy duty pneumatic cylinders


  • Heavy duty pneumatic cylinders using steel material as a main parts
  • Use of urethane dust wipers
  • ISO Standards apply (except to 140 and 180 mm bore cylinders).
  • The bore size from 32 to 250 mm are available.
  • Non-lubrication type

    Technical Specifications:

    Action Style Standard Type
    Note1)Available Bores(mm) φ 32,φ 40,φ 50,φ 63,φ 80,φ 100,φ 125,(φ 140),φ 160
    Mounting Style SD/LB/FA/FB/CA/CC/CB/CD/TA/TC
    Working Fluid Air
    Lubrication Not necessary(But possible)
    Operating Pressure Range 0.1 to 1MPa
    Proof Test Pressure 1.5MPa
    Operating Speed Range 50 to 700mm/s
    Operating Temperature -10 to +70 ºC(But do not use when frozen)
    Cushion Mechanism With cushion on both ends
    Thread Tolerance JIS 6g/6H
    Stroke Fabrication Range φ 32: to 800 φ 40: to 1200 φ 50/φ 63: to 1400
    φ 80/φ 100: to 1800 φ 125 to φ 250: to 2000
    Accessories Rod End Attachment Rod End Eye(T type)/Rod End Spherical Eye(S type)/Rod End Clevis(Y type)/F Joint
    Bracket CB&CD Bracket/TA&TC Bracket
    Note1)Dust Cover Standard:Nylon tarpaulin Semi-standard: Chloroprene/CONEX
